HSS PRO TIN DIN 338 6.5 - CYL
Product Code:
01-2592
DIN 338 Titanium. Cutting drills are made of high quality (HSS) high-speed steel and have a 2.5µ titanium nitride coating. TIN coating hardens the surface up to 80HRC and is wear-resistant. TIN coating causes less friction effect, therefore, a cutting drill drills faster and generates less heat. 135 degree double-sharpened drill is designed for faster speed and easier drill centering. Recommended to drill the materials the hardness limit of which is up to 1000 N/mm2.
| Manufacturer: IRWIN |
| Diameter, mm: 6.5 |
| Working Length, mm: 63 |
| Overall length, mm: 101 |
| Stem type: Straight |
| Standard: DIN 338 |
| For steel up to (N/mm2): 1000 |
| Aluminium: 2s |
| Drill tip angle: 135° |
| Cast Iron: 1s |
| Alloyed steel: 2s |
| Non-alloy steel: 3s |
| Stainless steel: 2s |
| Surface: TIN |
| Plastics: 3s |
| Sheet metal: 3s |
| Non-ferrous metals: 2s |
Barcode:
5709131283355
Unit of Measure Name:
Units
